Customer: Malaysian customers
Equipment name: the magnetron sputtering coating equipment
Equipment introduction:
This magnetron sputtering coating equipment system is a single chamber structure, mainly composed of sputering vacuum chamber,magnetron sputering target,rotating substrate table,heating system, DC power
suppy, RF power supply, working as path, hlim thiekes meter, vacuum acquisition system,imnstalation machine, vacuum measurement, water cooling and alarm system
and control system, etc. It can be used for the preparation of metal thin film, dielectric film, etc.
Customers come to our factory for acceptance
Application:
Magnetron sputtering coating technology is an efficient and controllable physical vapor deposition (PVD) method, which is widely used in many industrial and scientific research fields, mainly including:
Optical thin film: used to prepare anti-reflection film, reflective film, filter, etc., used in lenses, displays (such as AR/VR coating), solar cell anti-reflection layer, etc.
Electronic semiconductor: deposit conductive layer (such as aluminum, copper) or insulating layer (such as SiO₂, Al₂O₃) in integrated circuits to manufacture thin film transistors (TFT), LED electrodes, etc.
Wear-resistant and protective coating: TiN, CrN and other hard coatings are plated on the surface of tools and molds to improve hardness and corrosion resistance and extend service life.
Decorative coating: by sputtering metals or nitrides such as gold and titanium, the color and texture of mobile phone shells, watches and other products are optimized.
New energy field: preparation of thin-film solar cells (such as CIGS), solid-state battery electrode materials and fuel cell catalyst layers.
Scientific research and functional materials: used in the development of superconducting films, magnetic films (such as giant magnetoresistance materials) and biomedical coatings (such as antibacterial coatings).
This technology has become one of the core processes for modern precision manufacturing and high-end material research and development due to its uniform film formation, strong adhesion, and low-temperature deposition.
