Position:Home > Customers Case > Vacuum Furnace

500℃ vacuum sintering furnace - for heat treatment of metal components

Time：2025-04-15

　　
Customer: China XX Precious Metals Co., Ltd.

Equipment name: Vertical vacuum sintering furnace

Working temperature: ≤500℃

Processing materials: Vacuum heat treatment of metal components.

Equipment introduction：

This vertical vacuum furnace is a vacuum sintering furnace customized according to user requirements. The furnace adopts a lightweight ceramic fiber refined furnace chamber, and the heating element adopts molybdenum-containing resistance wire, which has a fast heating speed and high heating efficiency; it adopts PID intelligent program temperature control system, thyristor control, and high temperature control accuracy; the furnace chamber material is made of high-purity alumina polycrystalline fiber, which has good thermal insulation performance, durability, high tensile strength, no impurities, high purity, and energy-saving effect is significantly better than domestic fiber materials; three independent heating chambers share a vacuum chamber multi-cavity vacuum furnace, the vacuum degree can reach 1x10-2pa; independent electric control cabinet control, simple and convenient operation.

Vacuum furnace customer on-site real shot
