Bell Atmosphere Furnace with Glove Box
| Product name | DJZ melting unit |
| Model | Non-standard customized (KJ-A1000-E450-DZ) |
| shell structure | Double air cooling |
| Number of heating chambers | 2, each heating chamber has an independent control system |
| Effective size of heating chamber | Diameter 400*450 Height mm |
| Refractory | Alumina refractory fiber |
| Heating zone material | Stainless steel |
| Woking temperature | Continuous working temperature is less than or equal to 600°C; maximum temperature: 800°C |
| Temperature control method | 7-inch touch screen, PID controller, intelligent 30-segment programmable control |
| Heating rate | 0-10℃/min |
| Over temperature alarm | With over temperature and broken couple alarm function |
| Heating element | Molybdenum resistance wire |
| Thermocouple | K-type thermocouple temperature measurement |
| Furnace door opening method | Bottom automatic control lift |
| Furnace door seal | Furnace mouth installation sealing silicone strip |
| special requirements | The atmosphere furnace requires a sealed connection to a specific glove box |
| Glove box bracket from ground | 950mm(height adjustable) |
| Station | There are multiple operating stations, single-sided operation |
| Glove box material | 304 stainless steel, thickness 5mm |
| Working power | 380V Three-phase 50HZ |
