Model：KJ-T1200-S40K1

Mini Tube Furnace

Description：

KJ-T1200-S40K1 is a compact mini laboratory tube furnace with split structure, easy for you to put and take tubes. The top temperature is 1200℃ with a 30-segment programmable controller.

Email：web@kejiafurnace.com

Leave A Message

Online Chat

IntroductionFeaturesTechnical ParametersInquiryCustomer Case

Specific Introduction:
The quartz tube with flanges and the vacuum pump, it can work both for vacuum and atmosphere conditions.

Range of Application:
This mini tube furnace is mainly used for sintering, coating, Nanotube study, soldering in both vacuum condition and atmosphere condition in laboratories and enterprises.

Advantage:

Compact structure.
Low power dissipation.
Accurate control.
Easy operation.
Stable performance

features

1.Excellent dynamic sealing system can vacuum and ventilate the atmosphere. The furnace tube and the flange are extruded and sealed with a silicone O-ring, which is easy to remove and has strong sealing performance. It can be evacuated and filled with pr
2.Temperature control accuracy can reach ±1℃. The temperature control system adopts PID method and can set 30-stage temperature rising and cooling programs. The temperature control accuracy can reach ±1℃.
3.The furnace tube is made of high-purity quartz glass material, which has extremely low thermal expansion coefficient, high temperature resistance, good chemical stability and good electrical insulation.
4. At the same time, we can customize different temperatures, styles and control methods specifically for customers. Welcome to inquire.

Technical Parameters

Model	KJ-T1200-S25K1	KJ-T1200-S30K1	KJ-T1200-S40K1	KJ-T1200-S50K1
Top Temperature	1200℃
Working Temperature	1100℃
Quartz Tube Diameter (Customization)	Φ25mm	Φ30mm	Φ40mm	φ50mm
Heating zone length (Customization)	200/300mm
Insulation layers	High-Purity Alumina Ceramic fiber
Control Accuracy	±1℃
Temperature Sensor	N-type Thermocouple
Heating Element	0Cr27Al7Mo2 Resistance Wire
Sealing	Flanges
Structure	Split
Optional	Vacuum pumps, Gas-mixing system with mass flowmeters or float flowmeters.
