Product Introduction
The KJ-M1200-Z, KJ-M1400-Z, and KJ-M1700-Z series atmosphere furnaces are high-temperature hydraulic lifting atmosphere heat treatment equipment independently developed for laboratory research, new material development, and industrial small-batch production. This series covers three temperature grades from 1200℃ to 1700℃, fully meeting low, medium and high-temperature sintering, annealing, calcination, and heat treatment requirements of metals, ceramic materials, powder metallurgy, and inorganic composite materials.
Equipped with a stable hydraulic lifting and descending material tray system, the furnace realizes automatic material feeding and discharging, effectively avoiding temperature fluctuation caused by frequent door opening and improving experimental repeatability and production consistency. The whole furnace adopts high-purity alumina ceramic fiber insulation structure with excellent thermal insulation performance, fast heating speed and low energy consumption. Supported with inert gas atmosphere protection and vacuum environment treatment, it perfectly prevents material oxidation and solves the heat treatment difficulties of easily oxidizable and high-precision samples.With high-precision PID intelligent temperature control system and multi-type professional thermocouple matching, the furnace achieves ±1℃ precise temperature control, making it ideal standard heat treatment equipment for universities, research institutes, and industrial.
Application:
It’s an ideal furnace which can be used for heat treatment of heavy material in atmosphere condition with inert gas and so on in universities, laboratories and factories.
Parameters:
The KJ-M1200-Z, KJ-M1400-Z, and KJ-M1700-Z series atmosphere furnaces are high-temperature hydraulic lifting atmosphere heat treatment equipment independently developed for laboratory research, new material development, and industrial small-batch production. This series covers three temperature grades from 1200℃ to 1700℃, fully meeting low, medium and high-temperature sintering, annealing, calcination, and heat treatment requirements of metals, ceramic materials, powder metallurgy, and inorganic composite materials.
Equipped with a stable hydraulic lifting and descending material tray system, the furnace realizes automatic material feeding and discharging, effectively avoiding temperature fluctuation caused by frequent door opening and improving experimental repeatability and production consistency. The whole furnace adopts high-purity alumina ceramic fiber insulation structure with excellent thermal insulation performance, fast heating speed and low energy consumption. Supported with inert gas atmosphere protection and vacuum environment treatment, it perfectly prevents material oxidation and solves the heat treatment difficulties of easily oxidizable and high-precision samples.With high-precision PID intelligent temperature control system and multi-type professional thermocouple matching, the furnace achieves ±1℃ precise temperature control, making it ideal standard heat treatment equipment for universities, research institutes, and industrial.
Application:
It’s an ideal furnace which can be used for heat treatment of heavy material in atmosphere condition with inert gas and so on in universities, laboratories and factories.
Parameters:
| Model | KJ-M1200-Z | KJ-M1400-Z | KJ-M1700-Z |
| Max. Temperature | 1200℃ | 1400℃ | 1700℃ |
| Working Temperature | 1100℃ | 1300℃ | 1600℃ |
| Heating Element | Resistance Wire | SiC heating rod | MoSi2 heating rod |
| Tray Movement | Hydraulic Lifting and Descending System | ||
| Thermocouple | K-type | S-type | B-type |
| Insulation material | Alumina ceramic fiber | ||
| Heating rate | 0-20℃/min | ||
| Control Accuracy | ±1℃ | ||
| Heating Chamber Size/mm | 150x150x150 200x200x200 200x200x300 300x300x300 300x300x400 400x400x400 500x500x500 600x600x600 800x800x800 |
||
| Customization available to meet customer needs | |||
